Product Description:
The Heat Sink Thermal Pad is available in various thicknesses ranging from 0.3mm to 15mm, making it suitable for use in a wide range of applications, including computers, LED lighting, power supplies, and other electronic devices.
With a thermal conductivity rating of 0.8~15W/(m·K), this product can effectively transfer heat away from the source, thereby preventing overheating and damage to the electronic components. Its high thermal conductivity also means that it can reduce the operating temperature of the device, thereby improving its performance and extending its lifespan.
In addition, the Heat Sink Thermal Pad has a density of 3.0±0.5 G/cm³, which ensures that it provides a stable interface between the heat source and the heat sink. This density also ensures that the product remains intact and does not disintegrate or deform under high pressure or temperature.
At our company, we offer free samples of the Heat Sink Thermal Pad so that our customers can test the product for themselves before making a purchase. We are confident that this product will meet and exceed your expectations, and we are committed to providing excellent customer service and support.
Overall, if you are looking for a reliable and efficient solution to dissipate heat from your electronic devices, look no further than the Heat Sink Thermal Pad. With its excellent thermal conductivity, high density, and free sample offering, this product is the perfect choice for your heat dissipation needs.
Features:
- Product Name: Silicone Thermal Pad
- Breakdown Voltage: ≥10KV/mm
- Free Samples: Yes
- Thermal Conductivity: 0.8~15W/(m·K)
- Volume Resistivity: 1.0*10^13Ω*cm
- Thickness Range: 0.020-0.200mmT
- Material: High Temperature Silicone Rubber
- Usage: Heat Sink Thermal Pad, Conductive Silicone Rubber
Technical Parameters:
| Technical Parameter |
Value |
| Product Name |
CPU Thermal Pad / Heat Sink Thermal Pad / Heat Sink Thermal Pad |
| Colour |
Grey, Blue, Pink, Brown |
| Fire Performance |
V-0 |
| Operating Temperature |
-40°C To 200°C |
| Thickness |
0.3mm-15mm |
| Tensile Strength |
0.23MPa |
| Density |
3.0±0.5 G/cm³ |
| Weight Loss |
≤0.3 |
| Breakdown Voltage |
≥10KV/mm |
| Features |
Moldability For Complex Parts |
| Dielectric Constant |
3.49~9.8@1MHz |
Applications:
The product has obtained the certifications of ISO9001, ISO14001, and TS16949, which ensure the superior quality of the product. The Breakdown Voltage of this product is ≥10KV/mm, and the Thermal Conductivity is 0.8~15W/(m·K). The Density of the product is 3.0±0.5 G/cm³, and the Hardness is Shore 30±5. The Specific heat capacity at 25℃ is 1.0~0.5J/(kg•℃).
The Race GTP010~GTP012 Conductive Silicone Rubber Thermal Pad is a perfect solution for thermal management in electronic devices. With its excellent thermal conductivity and insulation properties, it provides an efficient heat transfer path between electronic components and heat sinks or other cooling devices.
The product is available in different sizes and thicknesses to meet the specific requirements of different electronic devices. The low MOQ and negotiable price make it an attractive option for small and medium-sized businesses.
The packaging details of the product can be customized according to customer requirements, and the delivery time is only 7 days. The payment terms are 30% TT in advance, and the balance payment is paid before shipment. The supply ability of this product is 1000000/Day, which ensures timely delivery of the product.
The Race GTP010~GTP012 Conductive Silicone Rubber Thermal Pad is the best solution for thermal management in electronic devices. Whether you are working with CPU, GPU, LED lighting, automotive electronics, or power electronics, this product will provide efficient thermal conductivity and insulation.
